1-10-77 1-10-78
Main CBA Parts Location Guide
Ref No. Position Ref No. Position Ref No. Position Ref No. Position
R008 G-3 R357 D-2 R510 C-1 R705 B-1
R009 F-2 R358 C-3 R511 C-2 R706 A-1
R011 G-3 R360 D-3 R513 C-2 R709 A-1
R012 G-3 R361 D-3 R514 C-2 R751 B-4
R013 F-3 R370 E-3 R516 C-1 R752 A-3
R014 F-3 R371 E-3 R517 C-1 R756 A-1
R015 F-3 R372 E-3 R518 C-2 R757 A-1
R016 F-3 R401 C-4 R519 C-2 R758 A-1
R017 F-2 R402 C-4 R520 E-2 R759 A-1
R018 F-2 R403 B-4 R521 E-2 R771 E-4
R021 F-2 R404 B-4 R522 D-2 R772 E-4
R022 F-2 R405 D-4 R523 C-1 R773 F-4
R023 F-2 R406 D-4 R524 C-1 R774 E-4
R024 F-2 R407 D-4 R525 C-1 R775 E-4
R025 F-2 R408 C-3 R526 E-1 R776 F-4
R026 G-2 R409 C-3 R527 D-1 R777 F-3
R027 G-2 R411 C-4 R528 A-1 R778 E-4
R028 G-3 R412 D-4 R529 D-2 R779 E-4
R035 G-2 R413 D-4 R530 C-2 R780 E-4
R054 F-1 R414 D-4 R531 C-2 R781 E-4
R059 F-1 R415 D-3 R533 E-2 R782 E-4
R060 G-1 R416 D-3 R534 F-2 R783 E-4
R061 F-1 R417 D-3 R535 F-2 R784 E-4
R062 F-1 R421 D-4 R536 F-2 R785 F-4
R063 F-1 R422 D-4 R537 F-1 R786 F-4
R064 F-1 R423 D-3 R538 E-2 R787 F-4
R065 F-1 R424 D-3 R539 F-1 R851 C-2
R066 F-2 R425 D-4 R540 B-1 R852 D-2
R067 F-1 R426 D-4 R541 B-1 R853 C-1
R068 F-1 R429 D-3 R542 B-1
R070 F-1 R430 D-3 R543 E-1 SW501 B-1
R157 B-2 R431 D-3 R544 E-1 SW502 B-1
R158 B-2 R451 B-3 R545 F-1 SW504 E-1
R251 C-3 R452 B-3 R546 G-1 SW505 F-1
R252 C-3 R453 B-3 R547 B-1 SW506 C-1
R301 D-3 R454 B-3 R551 C-2 SW507 F-1
R302 D-3 R455 B-3 R552 C-2
R303 D-3 R456 B-4 R555 C-1 VR501 A-1
R304 D-3 R457 B-3 R556 C-1
R305 D-3 R458 B-3 R557 C-1 X301 D-3
R306 C-2 R459 C-3 R558 C-1 X501 C-1
R307 C-3 R460 C-4 R566 E-1 X502 C-1
R308 C-3 R461 C-3 R601 C-2
R309 C-3 R462 C-3 R603 C-1 AC001 F-4
R310 B-2 R463 C-3 R604 C-1 F001 G-4
R311 B-2 R464 C-3 R605 D-2 FP562 D-1
R312 C-2 R465 C-3 R606 D-2 JK751 B-4
R313 C-2 R466 B-3 R607 D-2 JK756 A-1
R314 C-3 R467 B-3 R608 D-2 JK757 A-1
R315 C-3 R468 B-3 R609 C-1 JK758 A-1
R316 C-3 R469 B-3 R610 C-1 PS503 C-2
R317 C-3 R470 B-3 R612 B-1 RS501 C-1
R318 C-3 R471 B-3 R613 B-1 SA001 F-4
R319 C-3 R472 B-3 R614 B-1 T001 G-2
R320 C-3 R473 B-3 R615 B-1 TU701 A-3
R321 D-3 R474 C-3 R616 C-1
R322 D-3 R479 B-3 R617 C-2 TP301 G-1
R323 D-2 R480 B-3 R618 C-1 TP501 G-1
R324 C-3 R501 C-1 R621 D-2 TP502 B-1
R328 D-3 R502 B-1 R622 D-2 TP506 A-2
R330 D-3 R503 C-1 R623 E-2 TP507 G-1
R331 D-3 R504 C-1 R624 D-2 TP508 C-1
R332 D-3 R505 C-1 R625 D-5 TP751 B-2
R333 D-2 R506 C-1 R701 A-2
R351 C-2 R507 C-1 R702 A-1
R352 C-2 R508 A-1 R703 A-1
RESISTORSRESISTORSRESISTORS RESISTORS
SWITCHES
VARIABLE RESISTOR
CRYSTAL OSCILLATORS
MISCELLANEOUS
TEST POINTS
Ref No. Position Ref No. Position Ref No. Position Ref No. Position Ref No. Position
C002 G-3 C345 D-3 C476 B-3 C778 F-3 IC561 E-1
C003 F-3 C346 C-3 C477 B-3 C851 C-2 IC771 F-4
C004 G-3 C347 C-3 C478 B-3 C852 C-2
C005 G-3 C348 D-2 C479 B-3 C853 D-2 J902 F-3
C006 G-2 C351 C-3 C480 B-3 C854 D-2 L001 G-4
C007 F-3 C352 D-2 C481 C-3 C855 C-1 L002 F-3
C008 F-2 C370 D-3 C482 C-3 C856 C-1 L003 F-3
C010 G-3 C371 E-3 C483 C-3 C858 D-2 L009 G-1
C011 G-3 C372 D-3 C484 C-3 C859 C-1 L010 G-2
C012 F-2 C373 E-3 C485 C-3 C862 D-2 L012 F-1
C014 G-2 C374 D-3 C486 C-3 L251 C-3
C017 G-2 C375 D-3 C487 C-4 CL151 A-3 L301 C-3
C018 G-1 C376 D-3 C501 E-1 CL152 A-3 L370 E-3
C020 G-2 C377 D-3 C502 D-1 CL253 C-4 L401 B-4
C021 G-1 C378 D-3 C506 C-1 CL501 B-4 L402 D-3
C025 F-2 C379 E-4 C508 C-1 CL502 E-2 L451 C-3
C026 F-1 C381 E-3 C510 C-2 CL504 E-4 L452 C-2
C053 F-1 C382 E-4 C511 C-1 CL505 F-1 L501 E-1
C056 G-1 C383 E-3 C512 C-1 CL508 B-1 L561 E-1
C060 F-1 C384 E-4 C513 C-1 CL509 B-1 L562 E-1
C061 F-1 C401 C-4 C514 C-1 CN506 G-1 L701 A-4
C157 B-4 C402 C-4 C515 C-1 CN701 A-2 L702 A-2
C158 B-3 C403 C-4 C516 C-1 L703 A-2
C251 C-3 C404 C-4 C517 E-2 D001 G-4 L704 B-2
C252 C-3 C411 D-4 C518 E-2 D002 G-3 L705 A-2
C253 C-3 C412 D-4 C519 D-1 D003 G-3 L851 C-2
C254 C-3 C413 D-4 C520 D-1 D004 G-3 L853 C-1
C302 D-3 C414 D-4 C521 D-1 D005 G-3
C303 D-3 C415 D-4 C522 D-1 D006 G-3 Q001 G-2
C304 D-3 C416 D-3 C523 E-1 D007 F-2 Q002 G-2
C305 D-3 C417 D-3 C524 E-1 D008 G-3 Q003 F-3
C307 D-3 C418 D-4 C526 E-1 D009 F-3 Q004 F-2
C308 D-3 C419 D-3 C527 D-1 D011 F-2 Q051 F-2
C309 D-3 C421 D-4 C529 D-1 D012 F-2 Q052 F-2
C310 D-3 C422 D-3 C530 D-1 D013 F-2 Q053 F-1
C311 D-3 C423 D-3 C531 C-1 D014 G-2 Q054 F-1
C312 D-3 C424 D-4 C535 D-2 D015 G-2 Q056 F-1
C313 D-3 C425 D-3 C538 A-3 D018 G-3 Q057 F-1
C314 D-3 C427 D-3 C540 E-1 D019 F-2 Q058 G-1
C315 D-3 C428 D-4 C541 E-1 D021 F-2 Q153 B-2
C316 D-3 C430 D-3 C542 A-1 D051 F-2 Q351 C-2
C317 D-3 C431 C-3 C561 E-1 D052 F-1 Q352 D-3
C318 D-3 C451 B-3 C621 D-2 D053 G-1 Q401 C-4
C319 D-3 C452 B-3 C622 D-2 D056 G-2 Q402 B-4
C320 D-3 C453 B-3 C701 A-3 D057 F-1 Q403 D-4
C321 D-3 C454 B-4 C702 A-4 D151 B-4 Q404 D-4
C322 D-3 C455 B-4 C703 A-3 D152 A-3 Q405 D-4
C323 D-2 C456 C-3 C704 A-3 D153 B-3 Q406 D-4
C324 D-3 C457 B-4 C706 A-2 D154 B-3 Q451 C-3
C325 D-3 C458 C-4 C707 A-2 D155 A-3 Q501 C-1
C326 D-3 C459 C-4 C708 A-2 D156 A-3 Q502 D-1
C327 D-3 C460 C-3 C709 B-2 D157 B-4 Q503 D-2
C328 D-3 C461 C-3 C710 A-2 D301 C-3 Q504 F-3
C329 C-3 C462 C-4 C712 A-2 D370 D-3 Q505 A-3
C330 D-3 C463 C-3 C713 A-2 D501 E-1 Q551 C-2
C332 C-3 C464 C-4 C715 A-1 D502 D-2 Q552 C-2
C333 C-3 C465 C-3 C751 B-4 D552 C-2 Q621 D-2
C334 C-3 C466 C-3 C752 A-3 D553 C-2 Q771 F-3
C335 C-3 C467 C-3 C756 A-1 D621 D-2 Q772 F-3
C337 C-3 C468 C-3 C757 A-1 D701 A-2
C338 C-3 C469 C-3 C771 E-4 R001 F-3
C339 C-3 C470 C-3 C772 F-4 IC001 F-2 R002 G-3
C340 C-3 C471 C-3 C773 E-4 IC301 C-3 R003 G-3
C341 C-3 C472 C-3 C774 F-3 IC370 E-3 R004 G-3
C342 C-3 C473 C-3 C775 E-3 IC451 C-3 R005 G-3
C343 C-3 C474 C-3 C776 E-3 IC501 D-1 R006 G-3
COILS
TRANSISTORS
CONNECTORS
DIODES
ICS
CAPACITORS CAPACITORS CAPACITORS ICSCAPACITORS
RESISTORS
Comparison Chart of
Models and Marks
MODEL MARK
VR530/58 W
VR630/58 X
VR330/58 Y
VR730/58 Z
VR732/58 AA
VR830/58 AB
VRQ45/16 AC
VRQ45/39 AD
VRQ45/58 AE
