NOTES:
C…..±0.25% D…..±0.5% F…..±1%
G…..±2% J…..±5% K…..±10%
M…..±20% N…..±30% Z…..+80/-20%
ELECTRICAL PARTS LIST
Pos.
h
12 NC Description
MCV CBA
MAIN CBA (MCV-A)
2B7 9965 000 12286 SHIELD ASSEMBLY HC460ED 111111111
2B8 9965 000 08566 BUSH, LED(F) H3700UD 111111111
2B46 9965 000 12173 ROHM HOLDER H7770JD 111111111
A4 9965 000 13038 JACK BOARD(CONV) HC461BD 1 1 1 1 1
A4 9965 000 12406 JACK BOARD(CONV) HC480ED 1
AC001
h
9965 000 08666 AC CORD PE8B2CB1H0A-057 111111111
CAPACITORS
C002
h
9965 000 06521 METALLIZED FILM CAP. 0.068UF/250V K 111111111
C003
h
9965 000 06522 SAFETY CAP. 2200PF/250V 111111111
C004 9965 000 06566 ELECTROLYTIC CAP. 22UF/400V M(L?Z) 111111111
C005 4822 126 14142 CERAMIC CAP. B K 0.01UF/500V 111111111
C006 4822 126 14141 CERAMIC CAP. SL K 56PF/1KV 111111111
C007 CERAMIC CAP.(AX) X K 3300PF/16V 111111111
C008 CERAMIC CAP.(AX) X K 5600PF/16V 111111111
C010 FILM CAP.(P) 0.022UF/50V J 111111111
C011 ELECTROLYTIC CAP. 10UF/16V M 111111111
C012 ELECTROLYTIC CAP. 10UF/50V M H7 111111111
C014 ELECTROLYTIC CAP. 470UF/25V M 111111111
C017 ELECTROLYTIC CAP. 470UF/16V M 111111111
C018 ELECTROLYTIC CAP. 100UF/16V M 111111111
C020 ELECTROLYTIC CAP. 1000UF/16V M 111111111
C021 ELECTROLYTIC CAP. 470UF/10V M 111111111
C025 CERAMIC CAP.(AX) X K 5600PF/16V 111111111
C026 ELECTROLYTIC CAP. 47UF/16V M H7 111111111
C053 ELECTROLYTIC CAP. 330UF/6.3V M 111111111
C056 CERAMIC CAP.(AX) F Z 0.047UF/16V 111111111
C060 ELECTROLYTIC CAP. 10UF/16V M H7 11111111
C061 CHIP CERAMIC CAP. F Z 0.1UF/50V 11111111
C157 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C158 CHIP CERAMIC CAP. B K 1000PF/50V 111111111
C251 ELECTROLYTIC CAP. 10UF/16V M H7 111111111
C252 CHIP CERAMIC CAP. B K 1000PF/50V 111111111
C253 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C254 CHIP CERAMIC CAP. F Z 0.1UF/50V 111111111
C302 CHIP CERAMIC CAP. B K 0.022UF/50V 111111111
C303 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C304 ELECTROLYTIC CAP. 1UF/50V M H7 111111111
C305 CHIP CERAMIC CAP. F Z 0.1UF/50V 111111111
C307 CHIP CERAMIC CAP. B K 0.047UF/50V 111111111
C308 CHIP CERAMIC CAP. B K 0.022UF/50V 111111111
PRODUCT SAFETY NOTE: Products marked with a h
have special characteristics important to safety.
Before replacing any of these components, read carefully
the product safety notice in this service manual.
Don't degrade the safety of the product through improper servicing.
Parts that not assigned part numbers (-----------) are not
available.
Tolerance of Capacitors and Resistors are noted with
the following symbols.
VR330/58
VR530/58
VR630/58
VR730/58
VRQ45/58
VR732/58
VR830/58
VRQ45/16
VRQ45/39
To Next Page
