1-14-4 HC493PIN
26 -
N.U. Not Used
-
27
Y-
N.U. Not Used
-
W,X,
Z,
AA,
AB,
AC,
AD,
AE
OUT
RGB-
THROUGH
SCART 2 RGB
Through Control
Signal
L/Hi-z
28 -
N.U. Not Used
-
29 -
N.U. Not Used
-
30 -
N.U. Not Used
-
31 IN
REC-
SAF-SW
Recording Safety
SW Detect (With
Record tab="L"/
With out Record
tab="H")
H
32
W,X,
Y,Z,
AA,
AB,
AC,
AE
-
N.U. Not Used
-
AD IN
SECAM-
H
SECAM Mode at
High
H/L
33
W,X,
Y,Z,
AA,
AB,
AC,
AE
-
N.U. Not Used
-
AD OUT TRICK-H
Special
Playback = “H”
in SECAM Mode
H
34 IN
RESET
System Reset
Signal
(Reset=”L”)
L
35 IN
XC-IN Sub Clock
-
36 OUT
XC-OUT Sub Clock
-
37 -
Vcc Vcc
-
38 IN
X-IN Main Clock Input
-
39 OUT
X-OUT Main Clock Input
-
40 -
Vss Vss(GND)
-
41 -
N.U. Not Used
-
42 -
N.U. Not Used
-
43 IN
CLKSEL
Clock Select
(GND)
L
44 IN
OSC
IN
Clock Input
for letter size
-
45 OUT
OSC
OUT
Clock Output for
letter size
-
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
46 -
N.U. Not Used
-
47 -
LP LP
-
48 IN
FSC-IN
[4.43MHz]
4.43MHz Clock
Input
-
49 -
OSDVss OSDVss
-
50 IN
VIDEO-
IN
Video Signal
Input
-
51 -
N.U. Not Used
-
52 OUT
VIDEO-
OUT
Video Signal
Output
-
53 -
OSDVcc OSDVcc
-
54 -
HLF
LPF Connected
Terminal (Slicer)
-
55
AC -
N.U. Not Used
-
W,X,
Y,Z,
AA,
AB,
AD,
AE
IN
COLOR-
IN
SECAM or
MESECAM
Chroma Video
Input Signal at
Super Impose
Z/L
56 -
N.U. Not Used
-
57 -
N.U. Not Used
-
58 IN
C-SYNC
Composite
Synchronized
Pulse
PULSE
59 OUT
8POUT-1
SCART 1 8Pin
Output Control
Signal
H/L
60 OUT
8POUT-2
SCART 2 8Pin
Output Control
Signal
H/L
61
Y-
N.U. Not Used
-
W,X,
Z,
AA,
AB,
AC,
AD,
AE
IN
A-MODE
Hi-Fi Tape
Detection Signal
L
62 OUT SD-H SD-H -
63
W,X,
Y,Z,
AA,
AC,
AD,
AE
-
N.U. Not Used
-
AB OUT
LINK-
OUT
Easy Link Data
Output
Z/L
64 IN
FTV-IN
Comparator
Input of Video
Signal for Follow
TV
L/Hi-z
Pin
No.
Mark
IN/
OUT
Signal
Name
Function
Active
Level
