UM EN AXL F SYS DIAG
22
PHOENIX CONTACT 8663_en_03
2.2 Error codes for bus diagnostics
Table 2-2 Error codes for bus diagnostics
Code
(hex)
Additional code Meaning Remedy
0BD1 The bus could not be activated due to bus malfunctions. Check the bus configuration.
0BF1
0BF2
0BF3
0C01 Device number The configured module is not accessible.
A device present in the configuration frame has been re-
moved from the physical bus structure after the configu-
ration frame has been connected.
Check the configuration.
Adapt the configuration
frame if the modification was
done on purpose.
0C02 A module has been detected that was not configured.
An additional device was added at the end of the physi-
cal bus structure after the configuration frame was con-
nected.
0C11 The module is not located in the configured slot.
An active device was inserted at the different location of
the physical bus structure after the configuration frame
was connected.
0C12 The module is accessible but was not put into operation
due to missing parameters.
An active device was replaced by an unknown device in
the physical bus structure after the configuration frame
was connected (wrong instance ID).
0C13 The process data length does not correspond to the
configured value.
The process data width of an active device was changed
after the configuration frame was connected.
0C14 The module type does not correspond to the configured
value.
0C15 The module ID does not correspond to the configured
value.
