UM EN AXL F SYS DIAG
24
PHOENIX CONTACT 8663_en_03
6 Faulty access Check the call.
1 Invalid object
2 Hardware fault Eliminate the hardware error (e.g.,
I/O voltage not present).
Restart the device. If the problem still
occurs, please contact
Phoenix Contact.
3 Access to object denied Check the call.
4 Access to an invalid address Check the call.
5 Inconsistent object attributes
6 The service used cannot be applied to this ob-
ject.
7 Object does not exist
8 Type conflict
A Data not ready at present.
0 Other error
8 0 xx30 A reserved bit or reserved code was used
during parameterization.
xx: Number of the affected elements
30: Value is out of range
Check the parameterization.
1 Error writing the object Check the call.
Error reading the object
Table 2-3 Error codes when calling the PDI services [...]
Code
(hex)
Code
(hex)
Additional
code
Meaning Remedy
