8 - 19
8
05_156
05_246
- Assemble the thermal unit (cylinder, head, piston) as
described in Chapter 7-Thermal unit and Timing
system.
- Assemble the magneto flywheel with starting control
as described in Chapter 6-Flywheel and Starting
system.
- Assemble the flywheel cover with the cooling system
sleeves as described in Chapter 5-Flywheel cover.
05_245
- Assemble the driving pulley assembly, transmission
cover complete with net filter and the external trans-
mission cover as described in Chapter 3-Automatic
transmission.
05_006
Driving shaft crankcase
