Fuel injection
9 - 56
(3) Fuel pump
- Take note of the position of the feed wires on the
support
pos 1 = positive (red)
pos 4 = negative (black)
NOTE: the pump connections are not interchangeable.
- Disconnect the feed wires
- Cut the hose clamp from the delivery pipe on the
support
- Remove the fixing washer from the pump
- Remove the tube from the filter attachment
- Remove the pump complete with ring support and
prefilter
