8 - 3
8
05_245
05_246
05_156
05_006
- Remove the external transmission cover, the trans-
mission cover complete with net filter and the driving
pulley assembly as described in Chapter 3-Automatic
transmission.
- Remove the flywheel cover with the cooling system
sleeves as described in chapter 5-Flywheel cover
- Remove the magneto flywheel with the starting con-
trol as described in Chapter 6-Flywheel and Starting
System.
- Remove the thermal assembly (cylinder, head, pis-
ton) as described in Chapter 7-Thermal Assembly.
Driving shaft crankcase
