PIAGGIO Beverly 125 - Dashboard Controls

01_01
01_02
01_03
Dashboard (01_01, 01_02, 01_03)
A = Key switch
B = Starter button
C = Throttle grip
D = Front brake lever
E = Electric seat opening button
F = Odometer and speedometer
G = Turn indicator switch
H = Light switch
I = Rear brake lever
L = Horn button
M = RUN OFF (immobiliser) switch
N = Digital clock
R = Instrument and warning lights panel
8
1 Vehicle
