Specification Desc./Quantity
Lubrication Engine lubrication with lobe pump (inside crankcase) controlled
by a chain with double filter: mesh and paper.
Lubrication pressure 4 bar
Minimum lubrication pressure (100° C) 0.8 bar
Fuel supply KEIHIN CVEK 30 carburettor and electrical fuel pump.
Cooling Forced-circulation coolant system.
Fuel Unleaded petrol (95 RON)
Exhaust muffler absorption-type exhaust muffler with catalytic converter.
Emission regulations EURO 3
ENGINE 200
Specification Desc./Quantity
Type Single-cylinder, 4-stroke
Cubic capacity 198 cm³
Bore x stroke 72 x 48.6 mm
Compression ratio 11 ± 0.5 : 1
Engine idle speed 1650 ± 100 rpm
Timing system 4 valves, single overhead camshaft, chain-driven.
Valve clearance Inlet: 0.10 mm Outlet: 0.15 mm
MAX. power 14.5 kW at 9,000 rpm
MAX torque 16.5 Nm at 7.250 rpm
Lubrication Engine lubrication with lobe pump (inside crankcase) controlled
by a chain with double filter: mesh and paper.
Lubrication pressure 4 bar
Minimum lubrication pressure (100° C) 0.8 bar
Fuel supply KEIHIN CVEK 30 carburettor and electrical fuel pump.
Cooling Forced-circulation coolant system.
Fuel Unleaded petrol (95 RON)
Exhaust muffler absorption-type exhaust muffler with catalytic converter.
Emission regulations EURO 3
Transmission
TRANSMISSION
Specification
Desc./Quantity
Transmission Automatic expandable pulley variator with torque server, V-
belt, self-ventilating dry automatic centrifugal clutch and trans-
mission housing with forced-circulation air cooling.
Final reduction Gear reduction unit in oil bath.
Capacities
CAPACITY
Specification
Desc./Quantity
Engine oil 1.10 l
Transmission oil 250 cm³
Cooling system fluid ~ 2 l
Fuel tank (reserve) ~ 10 l (2 l)
Electrical system
ELECTRICAL SYSTEM 125
Specification
Desc./Quantity
Start-up Electric
Ignition Capacitive discharge ignition, with variable advance and sep-
arate HV coil.
Ignition advance 10° at 2.000 rpm - 29° at 6.750 rpm
Characteristics Carnaby 125 - 200
CHAR - 10
