PIAGGIO Carnaby 200 User Manual

Specification Desc./Quantity
Tapered pin stamping 306D
CUT-OFF device Not present
Diffuser Ø 29
Maximum jet 98
Minimum jet 35
Max. air jet 70
Minimum air jet 130
Throttle valve spring 100 ÷ 160 g
Minimum mixture set screw initial opening 2
Tapered pin Ø 2.45
Diffuser nozzle Ø 2.8
Starter air jet Ø 1.5
Starter jet 42
Starter device resistance ~ 20 Ω
Starter pin travel 10
200cc Version
Kehin
CARBURETTOR KEIHIN
Specification Desc./Quantity
Type Depression carburettor
Model CVK 30
Body stamping CVK
Tapered pin stamping 309D
CUT-OFF device Present
Diffuser Ø 29
Maximum jet 90
Minimum jet 35
Max. air jet 70
Minimum air jet 115
Throttle valve spring 150 ÷ 250 g
Minimum mixture set screw initial opening 2 ½
Tapered pin Ø 2.49
Diffuser nozzle Ø 2.8
Starter air jet Ø 1.5
Starter jet 42
Starter device resistance ~ 20 Ω
Starter pin travel 10
Tightening Torques
STEERING
Name
Torque in Nm
Upper steering ring nut 30 ÷ 36
Steering lower ring nut 10 ÷ 13 then loosen by 90°
Handlebar fixing screw (*) 45 ÷ 50
Fixing screws for handlebar control assembly U-bolts 7 ÷ 10
FRAME ASSEMBLY
Name
Torque in Nm
Bolt of the Silent block support plate 54
Frame arm-engine arm coupling pin nut 61
Frame-swinging arm pin nut 60
Engine-swinging arm bolt 40
Centre stand bolt 25 ÷ 30
Characteristics Carnaby 125 - 200
CHAR - 14

PIAGGIO Carnaby 200 Specifications

General

Engine Type	Single cylinder, 4-stroke
Displacement	198 cc
Fuel System	Carburetor
Cooling	Liquid cooled
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Weight	146 kg
Max Torque	17 Nm
Transmission	CVT
Rear Suspension	Two hydraulic shock absorbers with adjustable preload
Fuel Tank Capacity	7.5 liters
