The air passes through a rigid pipe connected to the head and reaches a discharge joint in order to
supply oxygen to the unburned gases before the catalytic converter, thus favouring an improved reac-
tion of the catalytic converter.
Carburettor
125cc Version
Kehin
CARBURETTOR KEIHIN
Specification
Desc./Quantity
Type Depression carburettor
Model CVK 30
Body stamping CVK
Carnaby 125 - 200 Characteristics
CHAR - 13
