- Undo the screws fixing the legshield to the frame
above the bag hook.
- Undo the screw «C» and remove the cover to
reach the expansion tank cap.
- Unscrew the expansion tank cap.
- Operating on both sides of the scooter, undo the
eight screws «D».
- Operating on both sides of the scooter, undo the
six screws «E» and remove the legshield.
Carnaby 125 - 200 Chassis
CHAS - 245
