- Undo the screws fixing the helmet compartment
to the frame.
- Undo the screws fixing the saddle lock.
- Undo the fuel tank cap, remove the rubber fuel
recovery tank and disconnect the bleed pipe.
- Remove the helmet compartment by pulling it upwards.
spoiler
- The lower spoiler is divided into two parts that can
be removed separately. The operations described
refer to one part but apply to both.
- Remove the footrest.
- Remove the lower centre screw and the external
screw.
Chassis Carnaby 125 - 200
CHAS - 252
