OPERATING AND INSTALLATION MANUAL HEAT PUMP COMBI UNIT PKOM4 PAGE 56
USER
GENERALSPECIALIST PERSONNEL
16. Installation/Operation of service software and firmware updates
The control unit must be connected to a
laptop via the micro-USB cable in order to
perform troubleshooting.
Further information on installation/op-
eration of service software and firmware
updates is available from certified partners
on request.
Service hotline: +43 (0)463 32769-290
Email: service@pichlerluft.at
17. Spare parts and accessories
Only original spare parts may be
used for mounting when repairs
and replacements are made.
The system can only be operated safely
when original spare parts are used.
17.1 CONTROL ELEMENTS
Designation Item number
STANDARD. TOUCH control unit 08PKOM4ES1086
Room CO
2
sensor for on-wall mounting 07RCO248330
Room humidity sensor for on-wall mounting 07RHF49360
Room temperature sensor for on-wall mounting 07RTF49357
Cables for control unit 40LG040340
17.2 SYSTEM COMPONENTS
Designation Item number
Heating circuit module PKOM
4
08PKOM4HBK33
Wall bracket set for heating circuit module 08PKOM4WHHBK33
External electric heating battery PKOM
4
, ø 160 mm, 1200 W 08CV16121MTXL
Duct temperature sensor with metal sleeve, NTC, cable length 2 m 40LG041920
Wall duct PKOM
4
, ø 160 mm 08PKOMMLA160
Wall duct PKOM
4
, ø 200 mm 08PKOMMLA200
17.3 AIR FILTER
Designation Item number
ETA filter ISO ePM10 75% (extract air), filter medium synthetic 40LG050280
ODA filter ISO ePM1 55% (outdoor air), filter medium glass fiibre 40LG050290
17.4 GATEWAY
Designation Item number
Modbus/KNX-Gatewax PKOM
4
08KNXGAPKOM4A
