Pichler PKOM4 - Passive House Certified to PHI Criteria

OPERATING AND INSTALLATION MANUAL HEAT PUMP COMBI UNIT PKOM4 PAGE 59
USER
GENERALSPECIALIST PERSONNEL
18.7 PASSIVE HOUSE CERTIFIED TO
PHI CRITERIA
Certificate
Passive House Suitable Component
For cool temperate climates
www.passivehouse.com
Category: Compact Heat Pump System
Manufacturer: Pichler G.m.b.H.
9021 Klagenfurt, AUSTRIA
Product name: PKOM 4
This certificate was awarded based on the following
criteria (limit values*):
Thermal Comfort: θ
supply air
≥ 16.5°C
Heat Recovery of ventilation system: η
WRG,eff
≥ 75%
Electric efficiency ventilation system: P
el
≤ 0.45 Wh/m³
Air tightness (internal/external): V
Leakage
≤ 3%
Total Primary Energy Demand (**): PE
total
≤ 55 kWh/(m²a)
Control and calibration (*)
Air pollution filters (*)
Anti freezing strategy (*)
Noise emission and reduction (*)
Measured values to be used in PHPP
useful air flow rates 121 to 192 m³/h
Heating
Test point 1 Test point 3 Test point 3 Test point 4
Outside Air
Temperature
T
amb -15 -7 2 7
°C
Thermal Output
Heating Heat Pump
P
WP,Heiz 0.612 0.933 0.771 0.776
kW
COP number Heating
Heat Pump
COP
Heiz
1.53 2.61 3.15 3.86
-
Maximum available supply air
temperature with Heat Pump only(*)
33 °C
Hot water
Test point 1 Test point 3 Test point 3 Test point 4
Outside Air
Temperature
T
amb
-7 2 7 20
°C
Thermal Output Heat
Pump for heating up
storage tank.
P
DHW
heating up
0.84 1.15 1.38 1.67
kW
Thermal Output Heat
Pump for reheating
storage tank
P
DHW
reheating
0.80 1.19 1.35 1.66
kW
COP Heat Pump for
heating up storage tank
COP
DHW,
heating up
2.28 2.97 3.34 3.94
-
COP Heat Pump for
reheating storage tank
COP
DHW
reheating
2.02 2.88 3.10 3.76
-
Average storage tank temperature
45
°C
Specific storage heat losses
1.51
W/K
Exhaust air addition (if applicable)
200
m³/h
(*) detailed description of criteria and key values see attachment.
(**) for heating, domestic hot water (DHW), ventilation, auxiliary electricity in the reference
building, explanation see attachment.
(***) All key values of heat pump were measured with enthalpy (humid) heat exchanger.
The dry heat recovery was measured, too and is shown here alternatively.
All other key values are valid respectively for dry heat recovery, too.
Passivhaus Institut
Dr. Wolfgang Feist
64283 Darmstadt
GERMANY
Heat Recovery by
enthalpy heat
exchanger(***)
η
WRG,eff
= 85%
alternative:
Dry Heat Recovery by
heat exchanger(***)
η
WRG,eff
= 88%
Electric efficiency
0.33 Wh/m³
Air tightness
V
leak, internal
= 0.8%
V
leak, external
= 1.4%
Frost protection
down to -15 °C
Total Primary Energy
Demand (**)
45 kWh/(m²a)
0875ch03
The current certificate can be downloaded at: www.pichlerluft.at/heat-pump-combination-unit.html
