PNOZ c1
Operating Manual PNOZ c1
22197-EN-06
| 14
Technical details
General
Certifications CCC, CE, EAC (Eurasian), TÜV, cULus Listed
Electrical data
Supply voltage
Voltage 24 V
Kind DC
Voltage tolerance -15 %/+10 %
Output of external power supply (DC) 2,5 W
Residual ripple DC 160 %
Duty cycle 100 %
Max. inrush current impulse
Current pulse, A1 1,8 A
Pulse duration, A1 4 ms
Inputs
Number 2
Voltage at
Input circuit DC 24 V
Start circuit DC 24 V
Feedback loop DC 24 V
Current at
Input circuit DC 30 mA
Start circuit DC 40 mA
Feedback loop DC 40 mA
Max. inrush current impulse
Current pulse, input circuit 0,35 A
Pulse duration, input circuit 25 ms
Current pulse, feedback loop 0,15 A
Pulse duration, feedback loop 2 ms
Current pulse, start circuit 0,15 A
Pulse duration, start circuit 2 ms
Min. input resistance at power-on 88 Ohm
Max. overall cable resistance Rlmax
Dual-channel with detection of shorts across con-
tacts at UB DC 15 Ohm
Relay outputs
Number of output contacts
Safety contacts (N/O), instantaneous 3
Auxiliary contacts (N/C) 1
Max. short circuit current IK 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1
