PNOZ c1
Operating Manual PNOZ c1
22197-EN-06
| 17
Environmental data
Airgap creepage
In accordance with the standard EN 60947-1
Overvoltage category III
Pollution degree 2
Rated insulation voltage 250 V
Rated impulse withstand voltage 6 kV
Protection type
Housing IP40
Terminals IP20
Mounting area (e.g. control cabinet) IP54
Mechanical data
Mounting position Any
Mechanical life 10,000,000 cycles
Material
Bottom PC
Top PC
Connection type Spring-loaded terminal
Mounting type Fixed
Conductor cross section with spring-loaded terminals
1 core flexible without crimp connector 0,25 - 1,5 mm², 24 - 16 AWG
1 core flexible with crimp connector 0,25 - 0,75 mm², 24 - 20 AWG
Spring-loaded terminals: Terminal points per connec-
tion 1
Stripping length with spring-loaded terminals 10 mm
Dimensions
Height 105 mm
Width 22,5 mm
Depth 100 mm
Weight 160 g
Where standards are undated, the 2020-07 latest editions shall apply.
