Operating Manual PNOZ c1
22197-EN-06
| 16
Relay outputs
External contact fuse protection, auxiliary contacts
Max. melting integral 260 A²s
Blow-out fuse, slow 6 A
Blow-out fuse, gG 6 A
Circuit breaker 24 V AC/DC, characteristic B/C 6 A
Contact material AgCuNi + 0,2 µm Au
Conventional thermal current while loading sev-
eral contacts
Ith per contact at UB DC; AC1:240V,DC1:24V
Conv. therm. current with 1 contact 6 A
Conv. therm. current with 2 contacts 6 A
Conv. therm. current with 3 contacts 5 A
Times
Switch-on delay
With automatic start typ. 250 ms
With automatic start max. 450 ms
With automatic start after power on typ. 250 ms
With automatic start after power on max. 450 ms
With manual start typ. 125 ms
With manual start max. 450 ms
Delay-on de-energisation
With E-STOP typ. 15 ms
With E-STOP max. 30 ms
With power failure typ. 60 ms
With power failure max. 100 ms
Recovery time at max. switching frequency 1/s
After E-STOP 300 ms
After power failure 300 ms
Supply interruption before de-energisation 20 ms
Simultaneity, channel 1 and 2 max. ∞
Environmental data
Climatic suitability EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C
Climatic suitability
Humidity 93 % r. h. at 40 °C
Condensation during operation Not permitted
EMC EN 60947-5-1, EN 61000-6-2, EN 61000-6-4, EN
61326-3-1
Vibration
In accordance with the standard EN 60068-2-6
Frequency 10 - 55 Hz
Amplitude 0,35 mm
