Page #7 background imageLoading...
Page #7 background image
- 7 -
Technische Daten Technical details Caractéristiques techniques
Elektrische Daten Electrical data Données électriques
Versorgungsspannung Supply voltage Tension d'alimentation
Versorgungsspannung U
B
DC Supply voltage U
B
DC Tension d'alimentation U
B
DC 24 V
Versorgungsspannung U
B
AC/DC Supply voltage U
B
AC/DC Tension d'alimentation U
B
AC/DC 48 - 240 V
Spannungstoleranz Voltage tolerance Plage de la tension d'alimentation -15 %/+10 %
Leistungsaufnahme bei U
B
AC Power consumption at U
B
AC Consommation U
B
AC 8,0 VA
Leistungsaufnahme bei U
B
DC Power consumption at U
B
DC Consommation U
B
DC 4,0 W
Frequenzbereich AC Frequency range AC Plage de fréquences AC 50 - 60 Hz
Restwelligkeit DC Residual ripple DC Ondulation résiduelle DC U
B
= 24 V DC: 20 %
U
B
= 48 – 240 V AC/DC: 160 %
Spannung und Strom an Voltage and current at Tension et courant sur
Eingangskreis DC: 24,0 V Input circuit DC: 24,0 V circuit d'entrée DC : 24,0 V 40,0 mA
Startkreis DC: 24,0 V Reset circuit DC: 24,0 V circuit de réarmement DC : 24,0 V 40,0 mA
Rückführkreis DC: 24,0 V Feedback loop DC: 24,0 V boucle de retour DC : 24,0 V 40,0 mA
Anzahl der Ausgangskontakte Number of output contacts Nombre de contacts de sortie
Sicherheitskontakte (S)
unverzögert:
Safety contacts (S) instantaneous: Contacts de sécurité (F)
instantanés :
2
Sicherheitskontakte (S) verzögert: Safety contacts (N/O), delayed: Contacts de sécurité (F)
temporisés :
2
Gebrauchskategorie nach
EN 60947-4-1
Utilisation category in accordance
with EN 60947-4-1
Catégorie d'utilisation selon
EN 60947-4-1
Sicherheitskontakte: AC1 bei 240 V Safety contacts: AC1 at 240 V Contacts de sécurité : AC1
pour 240 V
I
min
: 0,01 A , I
max
: 6,0 A
P
max
: 1500 VA
Sicherheitskontakte: DC1 bei 24 V Safety contacts: DC1 at 24 V Contacts de sécurité : DC1 pour
24 V
I
min
: 0,01 A , I
max
: 6,0 A
P
max
: 150 W
Sicherheitskontakte verzögert: AC1
bei 240 V
Safety contacts, delayed: AC1
at 240 V
Contacts de sécurité temporisés :
AC1 pour 240 V
I
min
: 0,01 A , I
max
: 6,0 A
P
max
: 1500 VA
Sicherheitskontakte verzögert: DC1
bei 24 V
Safety contacts, delayed: DC1
at 24 V
Contacts de sécurité temporisés :
DC1 pour 24 V
I
min
: 0,01 A , I
max
: 6,0 A
P
max
: 150 W
Gebrauchskategorie nach
EN 60947-5-1
Utilisation category in accordance
with EN 60947-5-1
Catégorie d'utilisation selon
EN 60947-5-1
Sicherheitskontakte: AC15 bei
230 V
Safety contacts: AC15 at 230 V Contacts de sécurité : AC15
pour 230 V
I
max
: 3,0 A
Sicherheitskontakte: DC13 bei 24 V
(6 Schaltspiele/min)
Safety contacts: DC13 at 24 V
(6 cycles/min)
Contacts de sécurité : DC13
pour 24 V (6 manœuvres/min)
I
max
: 4,0 A
Sicherheitskontakte verzögert:
AC15 bei 230 V
Safety contacts, delayed: AC15
at 230 V
Contacts de sécurité temporisés :
AC15 pour 230 V
I
max
: 3,0 A
Sicherheitskontakte verzögert:
DC13 bei 24 V (6 Schaltspiele/min)
Safety contacts, delayed: DC13
at 24 V (6 cycles/min)
Contacts de sécurité temporisés :
DC13 pour 24 V (6 manœuvres/min)
I
max
: 4,0 A
Kontaktmaterial Contact material Matériau des contacts AgCuNi + 0,2 µm Au
Kontaktabsicherung, extern
(I
K
= 1 kA) nach EN 60947-5-1
External contact fuse protection
(I
K
= 1 kA) to EN 60947-5-1
Protection des contacts en externe
(I
K
= 1 kA) selon EN 60947-5-1
Schmelzsicherung flink Blow-out fuse, quick Fusible rapide
Sicherheitskontakte: Safety contacts: Contacts de sécurité : 6 A
Sicherheitskontakte verzögert: Safety contacts, delayed: Contacts de sécurité temporisés : 6 A
Schmelzsicherung träge Blow-out fuse, slow Fusible normal
Sicherheitskontakte: Safety contacts: Contacts de sécurité : 4 A
Sicherheitskontakte verzögert: Safety contacts, delayed: Contacts de sécurité temporisés : 4 A
Sicherungsautomat 24V AC/DC,
Charakteristik B/C
Circuit breaker 24 VAC/DC, charac-
teristic B/C
Disjoncteur 24 V AC/DC, caractéris-
tique B/C
Sicherheitskontakte: Safety contacts: Contacts de sécurité : 4 A
Sicherheitskontakte verzögert: Safety contacts, delayed: Contacts de sécurité temporisés : 4 A
Halbleiterausgänge (kurz-
schlussfest)
Semiconductor outputs (short cir-
cuit proof)
Sorties statiques (protégées contre
les courts-circuits)
24,0 V DC, 20 mA
Max. Gesamtleitungswiderstand
R
lmax
Eingangskreise, Startkreise
Max. overall cable resistance
R
lmax
input circuits, reset circuits
Résistance max. de l'ensemble du
câblage R
lmax
circuits d'entrée, circuits de réar-
mement
einkanalig bei U
B
DC single-channel at U
B
DC monocanal pour U
B
DC 30 Ohm
einkanalig bei U
B
AC single-channel at U
B
AC monocanal pour U
B
AC 30 Ohm
zweikanalig ohne Querschlusser-
kennung bei U
B
DC
dual-channel without detect. of
shorts across contacts at U
B
DC
à deux canaux sans détection des
courts-circuits pour U
B
DC
30 Ohm
zweikanalig ohne Querschlusser-
kennung bei U
B
AC
dual-channel without detect. of
shorts across contacts at U
B
AC
à deux canaux sans détection des
courts-circuits pour U
B
AC
30 Ohm
zweikanalig mit Querschlusserken-
nung bei U
B
DC
dual-channel with detect. of shorts
across contacts at U
B
DC
à deux canaux avec détection des
courts-circuits pour U
B
DC
30 Ohm
zweikanalig mit Querschlusserken-
nung bei U
B
AC
dual-channel with detect. of shorts
across contacts at U
B
AC
à deux canaux avec détection des
courts-circuits pour U
B
AC
30 Ohm
