Operating Manual PNOZ X10
19554-EN-09
| 12
Preparing for operation
Supply voltage AC DC
A1
A2
L1
N
FE
A1
A2
L+
L-
Input circuit Single-channel Dual-channel
E-STOP
without detection of shorts
across contacts
S1
Y3
S12
S12
S21
S11
S22
S1
S11
S12
Y3
S22
S21
E-STOP
with detection of shorts across
contacts
S1
S22
S21
S12
S11
Y3
S11
Safety gate
without detection of shorts
across contacts
S1
Y3
S12
S12
S21
S11
S22
S1
S2
S22
S21
S11
S12
Y3
Safety gate
with detection of shorts across
contacts
Light guards or safety switch, de-
tection of shorts across contacts
via ESPE
(only when U
B
= 24 VDC)
NOTICE
With single-channel wiring the safety level of your machine/plant may be
lower than the safety level of the unit (see Safety characteristic
data [ 26]).
