PNOZ X10
Operating Manual PNOZ X10
19554-EN-09
| 16
Technical details Order no. 774700, 774701, 774703
General 774700 774701 774703
Certifications
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
CCC, CE, EAC (Euras-
ian), TÜV, cULus Listed
Electrical data 774700 774701 774703
Supply voltage
Voltage 24 V 42 V 110 - 120 V
Kind AC AC AC
Voltage tolerance -15 %/+10 % -15 %/+10 % -15 %/+10 %
Output of external
power supply (AC) 10 VA 10 VA 10 VA
Frequency range AC 50 - 60 Hz 50 - 60 Hz 50 - 60 Hz
Duty cycle 100 % 100 % 100 %
Inputs 774700 774701 774703
Number 2 2 2
Voltage at
Input circuit DC 24 V 24 V 24 V
Start circuit DC 24 V 24 V 24 V
Feedback loop DC 24 V 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA 50 mA
Start circuit DC 100 mA 100 mA 100 mA
Feedback loop DC 100 mA 100 mA 100 mA
Min. input resistance at
power-on 89 Ohm 89 Ohm 89 Ohm
Max. overall cable resist-
ance Rlmax
Single-channel at UB
AC 45 Ohm 45 Ohm 45 Ohm
Dual-channel without
detection of shorts
across contacts at UB
AC 90 Ohm 90 Ohm 90 Ohm
Dual-channel with de-
tection of shorts across
contacts at UB AC 15 Ohm 15 Ohm 15 Ohm
Relay outputs 774700 774701 774703
Number of output con-
tacts
Safety contacts (N/O),
instantaneous 6 6 6
Auxiliary contacts (N/C) 4 4 4
Max. short circuit current
IK 1 kA 1 kA 1 kA
Utilisation category
In accordance with the
standard EN 60947-4-1 EN 60947-4-1 EN 60947-4-1
