Operating Manual PNOZ X10
19554-EN-09
| 21
Technical details Order no. 774706, 774709
General 774706 774709
Certifications
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
CCC, CE, EAC (Eurasian), TÜV,
cULus Listed
Electrical data 774706 774709
Supply voltage
Voltage 230 - 240 V 24 V
Kind AC DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 10 VA –
Output of external power supply
(DC) – 5,5 W
Frequency range AC 50 - 60 Hz –
Residual ripple DC – 160 %
Duty cycle 100 % 100 %
Inputs 774706 774709
Number 2 2
Voltage at
Input circuit DC 24 V 24 V
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
Current at
Input circuit DC 50 mA 50 mA
Start circuit DC 100 mA 100 mA
Feedback loop DC 100 mA 100 mA
Min. input resistance at power-on 89 Ohm 89 Ohm
Max. overall cable resistance Rl-
max
Single-channel at UB DC – 45 Ohm
Single-channel at UB AC 45 Ohm –
Dual-channel without detection
of shorts across contacts at UB
DC – 90 Ohm
Dual-channel without detection
of shorts across contacts at UB
AC 90 Ohm –
Dual-channel with detection of
shorts across contacts at UB DC – 15 Ohm
Dual-channel with detection of
shorts across contacts at UB AC 15 Ohm –
Relay outputs 774706 774709
Number of output contacts
Safety contacts (N/O), instant-
aneous 6 6
Auxiliary contacts (N/C) 4 4
Max. short circuit current IK 1 kA 1 kA
