Operating Manual PNOZ X10
19554-EN-09
| 24
Conventional thermal current
while loading several contacts
774706 774709
Ith per contact at UB DC;
AC1:240V,DC1:24V
Conv. therm. current with 1 con-
tact – 8 A
Conv. therm. current with 2 con-
tacts – 8 A
Conv. therm. current with 3 con-
tacts – 7 A
Conv. therm. current with 4 con-
tacts – 6,1 A
Conv. therm. current with 5 con-
tacts – 5,4 A
Conv. therm. current with 6 con-
tacts – 5 A
Times 774706 774709
Switch-on delay
With automatic start typ. 180 ms 190 ms
With automatic start max. 250 ms 250 ms
With automatic start after power
on typ. 200 ms 200 ms
With automatic start after power
on max. 300 ms 300 ms
With manual start typ. 200 ms 200 ms
With manual start max. 250 ms 250 ms
With monitored start typ. 150 ms 165 ms
With monitored start max. 200 ms 220 ms
Delay-on de-energisation
With E-STOP typ. 20 ms 20 ms
With E-STOP max. 30 ms 30 ms
With power failure typ. 170 ms 170 ms
With power failure max. 250 ms 250 ms
Recovery time at max. switching
frequency 1/s
After E-STOP 50 ms 50 ms
After power failure 300 ms 300 ms
Min. start pulse duration with a
monitored start 50 ms 50 ms
Supply interruption before de-ener-
gisation 35 ms 35 ms
Environmental data 774706 774709
Climatic suitability EN 60068-2-78 EN 60068-2-78
Ambient temperature
Temperature range -10 - 55 °C -10 - 55 °C
Storage temperature
Temperature range -40 - 85 °C -40 - 85 °C
