TechnicalDetails
OperatingManualPNOZmc7p
1003050EN02
17
Environmentaldata
Airgapcreepage
Inaccordancewiththestandard EN611312
Overvoltagecategory III
Pollutiondegree 2
Ratedinsulationvoltage 30V
Protectiontype
Inaccordancewiththestandard EN60529
Mountingarea(e.g.controlcabinet) IP54
Housing IP20
Terminals IP20
Potentialisolation
Potentialisolationbetween Fieldbusandmodulevoltage
Typeofpotentialisolation Functionalinsulation
Ratedsurgevoltage 500V
Mechanicaldata
Mountingposition Horizontalontophatrail
DINrail
Tophatrail 35x7,5EN50022
Recesswidth 27mm
Material
Bottom PPOUL94V0
Front ABSUL94V0
Dimensions
Height 94,0mm
Width 22,5mm
Depth 122,0mm
Weight 110g
Wherestandardsareundated,the201203latesteditionsshallapply.

Pilz PNOZmulti Series Specifications

General

Mounting	DIN rail
Modular Expandability	Yes
Series	PNOZmulti
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Expansion Modules	Yes
Communication Interfaces	Ethernet
Configuration	Software-configurable
Safety Standards	EN ISO 13849-1, IEC 61508
SIL	SIL 3
PL	PL e
Supply Voltage	24 V DC
Operating Temperature	-20 °C to +60 °C (depending on the module)
