TechnicalDetails
OperatingManualPNOZmc7p
1003050EN02
16
8 TechnicalDetails
General
Approvals CCC,CE,GOST,cULusListed
Electricaldata
Supplyvoltage
for Modulesupply
Voltage 5,0V
Kind DC
Voltagetolerance 2%/+2%
Powerconsumption 2,5W
Statusindicator LED
Fieldbusinterface
Fieldbusinterface CCLinkV1.10
Unittype Slave
Stationaddress 0...63d
Transmissionrates 10MBit/s,156kbit/s,2,5MBit/s,5MBit/s,625kbit/
s
Connection 5pinCombiconpluginconnector
Assignedstations 2
Galvanicisolation Yes
Testvoltage 500VAC
Times
Supplyinterruptionbeforedeenergisation 20ms
Environmentaldata
Ambienttemperature
Inaccordancewiththestandard EN60068214
Temperaturerange 060°C
Storagetemperature
Inaccordancewiththestandard EN6006821/2
Temperaturerange 2570°C
Climaticsuitability
Inaccordancewiththestandard EN60068230,EN60068278
Humidity 93%r.h.at40°C
Condensationduringoperation Notpermitted
EMC EN611312
Vibration
Inaccordancewiththestandard EN6006826
Frequency 10,0150,0Hz
Acceleration 1g
Shockstress
Inaccordancewiththestandard EN60068227
Acceleration 15g
Duration 11ms
Max.operatingheightabovesealevel 2000m

Pilz PNOZmulti Series Specifications

General

Mounting	DIN rail
Modular Expandability	Yes
Series	PNOZmulti
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Expansion Modules	Yes
Communication Interfaces	Ethernet
Configuration	Software-configurable
Safety Standards	EN ISO 13849-1, IEC 61508
SIL	SIL 3
PL	PL e
Supply Voltage	24 V DC
Operating Temperature	-20 °C to +60 °C (depending on the module)
