Pilz PNOZmulti Series User Manual

Overview
OperatingManualPNOZmc7p
1003050EN02
6
2 Overview
2.1 Scopeofdelivery
} ExpansionmodulePNOZmc7p
} Jumper774639
2.2 Unitfeatures
UsingtheproductPNOZmc7p:
Expansionmoduleforconnectiontoabaseunitfromtheconfigurablecontrolsystem
PNOZmulti
Theproducthasthefollowingfeatures:
} CanbeconfiguredinthePNOZmultiConfigurator
} ConnectionforCCLink
} Stationaddressesfrom0...63,selectedviarotaryswitch
} Stationtype:RemoteDevice
} Occupiedstations:2
} 24virtualinputsandoutputsonthecontrolsystemPNOZmulticanbedefinedinthe
PNOZmultiConfiguratorforcommunicationwiththefieldbusCCLink.Thenumberof
inputsandoutputscanbeextendedto128.Pleasenotethatwhentheextendedinputs
andoutputs24127areusedtheyhavedifferentproperties(seedocumententitled
"CommunicationInterfaces").
} Max.1PNOZmc7pcanbeconnectedtothebaseunit
} Pleaserefertothedocument"PNOZmultiSystemExpansion"forthePNOZmultibase
unitsthatcanbeconnected.
2.3 Frontview

Pilz PNOZmulti Series Specifications

General

Mounting	DIN rail
Modular Expandability	Yes
Series	PNOZmulti
Number of Safety Inputs	Configurable
Number of Safety Outputs	Configurable
Expansion Modules	Yes
Communication Interfaces	Ethernet
Configuration	Software-configurable
Safety Standards	EN ISO 13849-1, IEC 61508
SIL	SIL 3
PL	PL e
Supply Voltage	24 V DC
Operating Temperature	-20 °C to +60 °C (depending on the module)
