Pioneer GEX-500DVB - Page 9

9
Appendix
Connection diagram
*Optional
ANT IN 1 ANT IN 2
AUDIO OUT
POWER SUPPLY
Antenna Set
VIDEO OUT
REMOTE
SENSOR
RS-232C
Set to “ON” with Active Antenna
This terminal isn’t used
Remote sensor
yellow
black
red
12V
+
-
GND
+12V
ACC
Monitor *
screw
screw
Mounting brackets
Mounting brackets
