108
KRP-500P
1
2 3 4
A
B
C
D
E
F
1
2 3 4
MTPFCA
PM S ETUP
PM BEZE L SET UP R 1<=>
ORY
1
5
10
15
16
1 5 10 15 20 25 30 32
I–N1 3 1010 –NTV HJ–B
Setup of the bezel can be performed on the PANEL MAIN BEZEL SETUP screen.
• Without the Panel Main Bezel setup, detection by the Room Light Sensor will not be performed properly.
• Even if Final setup (in System Operation mode [FSTS35] or in Display Standalone Operation mode [FSP]) is performed,
the initial value (R1) will not be restored.
[2-6] PANEL MAIN BEZEL SETUP
<DOWN> : Shifting to the next item
<UP> : Shifting to the previous item
<RIGHT> : Changing the setting value upward (+)
<LEFT> : Changing the setting value upward (-)
<ENTER/SET> : Determining the changed value
and return to the layer above
Select the bezel setup setting, using the L or R key, then press the SET key to determine the setting.
When NO OPT is selected, bezel setup is not performed.
Each time the L or R key is pressed, setup settings are changed, as shown below:
R1 R2 R3 EP NO OPT
“NO OPT” is selected immediately after the PANEL MAIN BEZEL SETUP screen is displayed.
R1: The bezel setup is performed according to ROM table 01. (Default)
R2: The bezel setup is performed according to ROM table 02.
R3: The bezel setup is performed according to ROM table 03.
EP: The bezel setup is performed according to the EEPROM table. (For use by engineers)
NO OPT: Bezel setup is not performed.
g Key operation
MTPFCA
PM S ETUP
PM NG C LEAR CLEAR<=>
ORY
1
5
10
15
16
1 5 10 15 20 25 30 32
I–N1 3 1010 –NTV HJ–B
The shutdown logs can be cleared on the PM NG CLEAR screen.
[2-7] PANEL MAIN NG CLEAR
<DOWN> : Shifting to the next item
<UP> : Shifting to the previous item
<RIGHT> : Changing the setting value upward (+)
<LEFT> : Changing the setting value upward (-)
<ENTER/SET> : Determining the changed value
and return to the layer above
“NG CLEAR” denotes clearing of the SD logs managed by the Panel Main microcomputer.
Select the setting, using the L or R key, then press the ENTER/SET key to clear the data.
When NO OPT is selected, NG CLEAR is not performed.
Pressing the L or R key toggles between CLEAR and NO OPT, as shown below:
CLEAR NO OPT
g Key operation
