Before Beginning Adjustments
7 PDP-425CMX/PDP-42MXE10★
Variable range
(STEP)
Factory setting
PDP-425CMX/PDP-42MXE10
INPUT1 INPUT2
PC signal
Video signal
★
PC signal
Video signal
★
Analog RGB
Component
RGB
Digital RGB Digital HDCP
PICTURE CONTRAST 0 to +255 +128
BRIGHTNESS 0 to +255 +128
H.ENHANCE 0 to +15 0
V.ENHANCE 0 to +15 0
COLOR 0 to +127 +64
TINT 0 to +60 +30
SHARPNESS 0 to +15 +8
WHITE BALANCE R.HIGH 0 to +255 +128
G.HIGH 0 to +255 +128
B.HIGH 0 to +255 +128
R.LOW 0 to +255 +128
G.LOW 0 to +255 +128
B.LOW 0 to +255 +128
COLOR DETAIL RED 0 to +60 +30
YELLOW 0 to +60 +30
GREEN 0 to +60 +30
CYAN 0 to +60 +30
BLUE 0 to +60 +30
MAGENTA 0 to +60
–
+30
C.DETAIL RESET NO
GAMMA 1.8 to 2.4 2.2
SCREEN H.POSITION 0 to +255 (for PC signal)
0 to +127 (for video signal)
+128
(for PC signal)
+64
(for video signal)
V.POSITION 0 to +255 (for PC signal)
0 to +127 (for video signal)
+128
(for PC signal)
+64
(for video signal)
CLOCK 0 to +255 +128
PHASE 0 to +31 +16
H.SIZE 0 to +63 0
V.SIZE 0 to +63 0
SETUP BRT.ENHANCE OFF-ON OFF
SUB VOLUME 0 to 20 20
OPTION
(Page 1)
PROGRAM TIMER Refer to pg. 163 Refer to pg. 163
SCREEN MASK OFF-INVERSE-WHITE-RED-
GREEN-BLUE-YELLOW
OFF
SIDE MASK R.LEVEL 0 to +255 +80
G.LEVEL 0 to +255 +80
B.LEVEL 0 to +255 +80
VIDEO WALL DIVIDER 1-4-9-16-25 OFF
POSITION Refer to pg. 166 Refer to pg. 166
TYPE NORMAL-ADJUSTED NORMAL
AUTO ID ON-OFF OFF
P.ON DELAY OFF-ON-MODE1-MODE2 OFF
ABL LINK ON-OFF OFF
REPEAT TIMER Refer to pg. 169 Refer to pg. 169
BAUD RATE 9600BPS-19200BPS-38400BPS-
1200BPS-2400BPS-4800BPS
9600BPS
ID NO.SET ALL-01H to FFH ALL
OPTION
(Page 2)
FAN CONTROL AUTO-MAX AUTO
OSD DISPLAY ON-OFF ON
SIZE LARGE-SMALL LARGE
ANGLE H-V H
FRONT INDICATOR ON-OFF ON
COLOR MODE NORMAL-STUDIO NORMAL
PRO USE UNDERSCAN ON-OFF OFF
IMAGE PROCESS NORMAL-PURE-
MONO TONE-HIGH CNT
NORMAL
SIGNAL TYPE MOTION-STILL-NON-STD MOTION
FRC ON-OFF ON
OPTION
(Page 3)
PWR.ON MODE INPUT LAST-INPUT1-INPUT2-INPUT3-
INPUT4-INPUT5-MULTI
★
LAST
VOLUME LAST-0-42 LAST
SEAMLESS SW SEAMLESS SW ON-OFF OFF
SELECT1 INPUT1-INPUT2-INPUT3-
INPUT4-INPUT5
★
INPUT1
SELECT2 INPUT1-INPUT2-INPUT3-
INPUT4-INPUT5
★
INPUT2
MIRROR MODE OFF-X-Y-XY OFF
MULTISCREEN SET S BY S SIZE NORMAL-FULL NORMAL
S BY S LAYOUT MODE 1-MODE 2-MODE 3 MODE1
PIP SIZE 1-4 2
TRANSLUCENT PIP 80%-70%-60%-50%-40%-
30%-20%-10%-OFF
OFF
BANNER PIP OFF-TOP-MID-HIGH-MID-LOW-
BOTTOM
OFF
BANNER INPUT INPUT1-INPUT2 INPUT1
: INPUT3 to INPUT5 are applicable only when the PDA-5003 or the PDA-5004 is installed.
(Note) The OPTION settings are common settings for all inputs.
