Pioneer PDP-425CMX

88
Speaker System: PDP-S44-LR
4.10 Speaker System: PDP-S44-LR
4.10.1 Specifications
External dimensions ................. 90 mm (W) × 610 mm (H) × 94.4 mm (D)
(3-1/2 in. (W) × 24-1/32 in. (H) × 3-22/32 in. (D))
When mounted to the Plasma Display:
1204 mm (W) × 610 mm (H) × 98 mm (D)
(48-1/32 in. (W) × 24-13/16 in. (H) × 4-1/16 in. (D))
Weight ....................................... 3.8 kg (8.4 lbs.)
34.3 kg (75.6 lbs.) (when mounted to the Plasma Display)
Dimensions of packaging......... 660 mm (W) × 260 mm (H) × 330 mm (D)
(27-5/16 in. (W) × 6-5/8 in. (H) × 12-17/32 in. (D))
Package weight......................... 6.2 kg (13.7 lbs.)
Cabinet....................................... Enclosed type, antimagnetic design
Used speakers (two-way method):
Woofer (for low tones) ....... 8 cm cone type
Tweeter (for high tones) .... 5 cm cone type
Nominal impedance ................. 6 Ω
Frequency Range ...................... 70 Hz to 20 000 Hz
Sensitivity.................................. 84 dB/W (at 1 m distance)
Permissible input:
Max. input ............................ 30 W
Rated input .......................... 10 W
Crossover frequency................. 250 Hz
Accessory parts (for 2 speakers)
Cushion ............................................................... × 2
Connection cord .................................................. × 2
Cord clamp .......................................................... × 2
Screw (M8).......................................................... × 4
Washer M8 (ø25) ................................................ × 2
Cautions
The sound may be irregular if there is a CRT type PC monitor close to the speakers. To prevent this, keep speakers
separated from the PC if you are using a CRT monitor.
