Pioneer PDP-425CMX User Manual

83
Mobile Cart: PDK-5014
4.9.2 External Dimensions
7 When using Plasma Display
(Units: mm)
(Stand shelf)
100
65
30
55
100
496
90
180
123.8
666.6
59
600
630
660
120
919.5 (Panel)
43
30
337
32.3
180
1084.5
1314
233.3
75
555
110
390
321.5
(Stand shelf installed at the lowest position)
721.5 (Stand shelf installation spacing 40 mm)
761.5 (Stand shelf installed at the highest position)
1350 (Center of the display screen when it is installed at the upper position)
1170 (Center of the display screen when it is installed at the lower position)
(673)
(723)
1022
300
35
312.5
1655
1510
765
(Stand shelf)
1 440
2 430
1 220
2 230
60
720
406
ø60
1 650
2 670
1 710
2 730
22
(Tilt angle)
5°
Note: Dimensions
1 : Compatible with Serial Nos. 1 to 510 of PDK-5014
2 : Compatible with Serial No. 511 and higher of PDK-5014
