Ceiling Mount Unit: PDK-5012
4.8.2 External Dimensions
7 When using Plasma Display
(Unit: mm)
4-φ13.5X22
129
98
47 1062
110
67
80
277
(493)
329 100
φ
70
φ240.5
211
300
200
1022
758
980
496
(530)
300
R
580
R5
10
45°
45°
610
φ60.5
This circle shows the path that the outermost
part of the Plasma Display follows when it is
rotated on a vertical axis after having been
titled sideways by 25°.
This circle shows the path that the outermost
part of the Plasma Display follows when it is
rotated on a vertical axis after having been titled
sideways by 25°.
Attachment
holes
(6 locations)
