207
RS-232C Adjustment
Sequence Data Content Size Remarks
27 PRO USE UNDERSCAN 1 Byte 0: OFF 1: ON
28 PRO USE IMAGE PROCESS 1 Byte 1: NORMAL 2: PURE 3: MONOTONE 4: HIGH CONTRAST
29 PRO USE SYGNAL TYPE 1 Byte 1: MOTION 2: STILL 3: NONE STD
30 FRC 1 Byte 0: OFF 1: ON
31 POWER ON MODE INPUT 1 Byte See the figure below.
32 POWER ON MODE MULTI MODE 1 Byte See the figure below.
33 POWER ON MODE MULTI INPUT 1 1 Byte 1: INPUT 2: INPUT2 3: INPUT3 4: INPUT4 5: INPUT5
34 POWER ON MODE MULTI INPUT 2 1 Byte 1: INPUT 2: INPUT2 3: INPUT3 4: INPUT4 5: INPUT5
35 POWER ON MODE VOLUME 2 Byte 0 to 42: In the case of lost memory, FF
36 SEAMLESS SW 1 Byte 0: OFF 1: ON
37 SEAMLESS SW SELECT1 1: INPUT 2: INPUT2 3: INPUT3 4: INPUT4 5: INPUT5
38 SEAMLESS SW SELECT2 1 Byte 1: INPUT 2: INPUT2 3: INPUT3 4: INPUT4 5: INPUT5
39 MIRROR MODE 1 Byte 0: OFF 1: X 2: Y 3: XY
40 MULTI SCREEN SET (S BY S SIZE) 1 Byte 1: NORMAL 2: FULL
41 MULTI SCREEN SET (S BY S LAYOUT) 1 Byte 1: MODE1 2: MODE2 3: MODE3
42 MULTI SCREEN SET (PIP SIZE) 1 Byte 1: 1 (SMALL) to 4: 4 (LARGE)
43 MULTI SCREEN SET (TRANSLUCENT) 1 Byte 0: OFF 1: 10 % 2: 20 % 3: 30 % 4: 40 % 5: 50 %
6: 60 % 7: 70 % 8: 80 %
44 MULTI SCREEN SET (BANNER PIP) 1 Byte 0: OFF 1: TOP 2: MID HIGH 3: MID LOW 4: BOTTOM
45 MULTI SCREEN SET (BANNER INPUT) 1 Byte 1: INPUT1 2: INPUT2
46 Main input function 3 Byte Same as item 9 of QST commands
47 Main screen size information 1 Byte Same as item 11 of QST commands
48 Check sum 2 Byte
49 ETX 1 Byte 03hex
7) <QSU> obtaining the audio status
Sequence Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QSU (fixed)
3 Main volume 3 Byte 000 to 042
4 Audio mute status 1 Byte 0: OFF 1: ON
5 INPUT1 sub volume 3 Byte 000 to 020
6 INPUT2 sub volume 3 Byte 000 to 020
7 INPUT3 sub volume 3 Byte 000 to 020
8 INPUT4 sub volume 3 Byte 000 to 020
9 INPUT5 sub volume 3 Byte 000 to 020
10 Check sum 2 Byte
11 ETX 1 Byte 03hex
8) <QCI> Obtaining time information
Sequence Data Content Size Remarks
1 STX 1 Byte 02hex
2 Command echo-back 3 Byte QCI (fixed)
3 Time information 2 Byte Hour (24 hour system) 00 to 23 Note 1)
2 Byte Minute 00 to 59 Note 1)
2 Byte Second 00 to 59 Note 1)
4 Dummy data 8 Byte
5 Day of week 1 Byte 1: Sunday 2: Monday 3: Tuesday 4: Wednesday
5: Thursday 6: Friday 7: Saturday Note 1)
6 Check sum 2 Byte
7 ETX 1 Byte 03hex
Note 1) During standby and when this command was initially set, the value at the time that power was finally shut off is transmitted.
