Pioneer PDP-425CMX

27
Special Installation (Mounting to fittings)
35 mm or
less
Attach so that
the fan is on
the left side
when viewed
from the rear.
Example 1
Example 2
Example 3
35 mm or
less
Example 4
Example 5
35 mm or
less
Example 6
35 mm or
less
Vertical installation
Standard installation
(In cases where top and bottom are reversed)
