Pioneer PDP-435PG

PDP-435PE
11
5678
56
7
8
C
D
F
A
B
E
CHASSIS SECTION (1) PARTS LIST
(2) CONTRAST TABLE
PDP-435PE/WYVIXK, PRO-435PU/KUC and PDP-435PE/WYVI are constructed the same except for the following :
Mark
No. Description Part No.
1 DIGITAL VIDEO Assy AWV2074
NSP 2 P. Chassis (435) Assy See Contrast table (2)
NSP 3 43 ADDRESS Assy AWZ6862
NSP 4 43 SCAN A Assy AWZ6873
NSP 5 43 SCAN B Assy AWZ6874
NSP 6 X CONNECTOR A Assy AWZ6875
NSP 7 X CONNECTOR B Assy AWZ6876
8PANEL SENSOR Assy AWZ6872
9 KEY CONTROL Assy AWZ6844
10 FPC (114P) ADY1088
11 Flexible Cable (J201) ADD1215
12 Flexible Cable (J202) ADD1227
13 Flexible Cable (J203) ADD1217
14 Flexible Cable (J204) ADD1218
15 Flexible Cable (J205) ADD1219
16 Flexible Cable (J206) ADD1220
17 Flexible Cable (J207) ADD1221
18 Flexible Cable (J208) ADD1222
19 Flexible Cable (J209) ADD1223
20 Flexible Cable (J210) ADD1224
21 Y Drive Protect Sheet AMR3346
22 Flat Clamp AEC1879
23 PCB Spacer AEC1941
24 PCB Support AEC1938
25 PCB Spacer AEC1944
26 PCB Support AEC1958
27 Wire Saddle AEC1745
28 PCB Spacer AEC1947
29 Wire Clip AEC1948
30 Nylon Rivet AEC1671
31 Screw VBB30P080FNI
32 Screw ABZ30P060FTC
33 Screw PMB30P060FNI
34 Edge Card Spacer AEC1998
NSP 35 Card Spacer AEC2013
Mark
No. Description Part No.
Mark No. Symbol and Description
PDP-435PE
WYVI
PDP-435PE
WYVIXK
PRO-435PU
KUC
NSP 2 P. Chassis (435) Assy AWU1091 AWU1091 Not used
NSP 2 P. Chassis (435) Assy B Not used Not used AWU1104
