6. ADJUSTMENT
6.1 ADJUSTMENT REQUIRED WHEN THE SET IS REPAIRED OR REPLACED
1. At shipment, the unit is adjusted to its best conditions. Normally, it is not necessary to readjust even if an assembly is replaced. If the
adjustment is shifted or if it becomes necessary to readjust because of part replacement, etc., perform the adjustment as described below.
2. Any value changed in Service/Factory mode will be stored in memory as soon as it is changed. Before readjustment, take note of the
original values for reference in case you need to restore the original settings.
3. Use a stable AC power supply.
43 Y DRIVE Assy No adjustment required
POWER SUPPLY Unit No adjustment required
DIGITAL VIDEO Assy
Writing of backup data is required.
Refer to the "7.1.7 BACKUP WHEN THE MAIN UNIT IS
ADJUSTED. "
43 X DRIVE Assy No adjustment required
Other assemblies
No adjustment required
Service Panel
Refer to the "6.4 METHOD FOR REPLACING THE
SERVICE PANEL ASSY. "
POWER SUPPLY Unit
DIGITAL VIDEO Assy No adjustment required
Refer to the "6.2 DRIVE ASSY ADJUSTMENT."
Refer to the "6.2 DRIVE ASSY ADJUSTMENT."
43 X DRIVE Assy (IC1101, IC1102)
43 Y DRIVE Assy (IC2201, IC2202)
Other assemblies No adjustment required
When any of the following assemblies is replaced
When any part in the following assemblies is replaced
The assembly must be replaced as a unit, and no part
replacement is allowed.
