7. GENERAL INFORMATION
7.1 DIAGNOSIS
7.1.1 PCB LOCATION
43 ADDRESS
Assy
43 ADDRESS
Assy
43 ADDRESS
Assy
43 ADDRESS
Assy
43 ADDRESS
Assy
X CONNECTOR B
Assy
43 ADDRESS
Assy
PANEL SENSOR
Assy
POWER SUPPLY
Unit
DIGITAL VIDEO
Assy
43 SCAN B
Assy
43 Y DRIVE
Assy
43 SCAN A
Assy
PANEL KEY
Assy
PANEL IR
Assy
PANEL IF
Assy
HD SP TERMINAL
Assy
HD AUDIO
Assy
PANEL LED
Assy
KEY CONTROL
Assy
43 ADDRESS
Assy
43 ADDRESS
Assy
X CONNECTOR A
Assy
43 X DRIVE
Assy
Rear view
