Pioneer PDP-435PG User Manual

2
A
B
C
D
1
23
4
1234
PDP-435PG
1. CONTRAST OF MISCELLANEOUS PARTS
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
560
47k
0.5
1
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k RN1/4PC F562 x 10
1
5621
PDP-435PG/TLDPFR and PDP-435PE/WYVI are constructed the same except for the following :
PACKING
P9 - 1 > Power Cord ADG1214 Not used
P9 - 7 NSP Warranty Card ARY1114 Not used
P9 - 14 Upper Carton (435PE) AHD3264 Not used
P9 - 14 Upper Carton (435PG) Not used AHD3296
P9 - 15 Vinyl Bag AHG1340 Not used
Label (43) AAX3144 Not used
REAR SECTION
P18 - 3 NSP Name Label (435PE) AAL2567 Not used
P18 - 3 NSP Name Label (435PG) Not used AAL2597
CONTRAST TABLE
Part No.
PDP-435PE
WYVI
Ref. No.
Symbol and Description
Remarks
Mark
PDP-435PG
TLDPFR
