Pioneer PDP-435PG User Manual

PDP-435PE
32
1234
1234
C
D
F
A
B
E
CN5601 (D1)
CN5602 (D2)
• Voltages
No. Signal Name I/O Signal Description Voltages at NTSC Signal Input
1 +12V I
+12V power input
+12VDC
2 +12V I
+12V power input
+12VDC
3 GND_D
−
GND
4 GND_D
−
GND
5PD O
Power down signal
0VDC
6 VSUS_ADJ O
VSUS adjustment signal
7 PS_PD I
Power-down detecting signal of POWER SUPPLY block
0VDC
8 RELAY O
Relay control signal
+3.3VDC
9 DRF O
Drive control signal
0VDC
10 AC_DET I
Primary side power (AC) state output at panel side
+3.0VDC
11 PD_TRIGGER I
Power down trigger
+3.3VDC
No. Signal Name I/O Signal Description Voltages at NTSC Signal Input
1 VADR I
Address drive power (+61V) input
+61VDC
2 VADR I
Address drive power (+61V) input
+61VDC
3 N.C
Not connected
4 GND_ADR
−
GND
5 GND_ADR
−
GND
6 +6.5V I
+6.5V power input
+6.8VDC
7 GND_D
−
GND
