GSD: Obtaining information on shutdown
Order Data Size Remarks
1
Latest SD data
1 byte 0 - 5
2
Latest SD subcategory data
1 byte 0 - 3
3
Data of hour meter for the latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
4
Data on temperature for the latest SD (TEMP1)
3 bytes 000 - 255
5
Second latest SD data
1 byte 0 - 5
6
Second latest SD subcategory data
1 byte 0 - 3
7
Data of hour meter for the second latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
8
Data on temperature for the second latest SD (TEMP1)
3 bytes 000 - 255
9
Third latest SD data
1 byte 0 - 5
10
Third latest SD subcategory data
1 byte 0 - 3
11
Data of hour meter for the third latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
12
Data on temperature for the third latest SD (TEMP1)
3 bytes 000 - 255
13
Fourth latest SD data
1 byte 0 - 5
14
Fourth latest SD subcategory data
1 byte 0 - 3
15
Data of hour meter for the fourth latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
16
Data on temperature for the fourth latest SD (TEMP1)
3 bytes 000 - 255
17
Fifth latest SD data
1 byte 0 - 5
18
Fifth latest SD subcategory data
1 byte 0 - 3
19
Data of hour meter for the fifth latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
20
Data on temperature for the fifth latest SD (TEMP1)
3 bytes 000 - 255
21
Sixth latest SD data
1 byte 0 - 5
22
Sixth latest SD subcategory data
1 byte 0 - 3
23
Data of hour meter for the sixth latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
24
Data on temperature for the sixth latest SD (TEMP1)
3 bytes 000 - 255
25
Seventh latest SD data
1 byte 0 - 5
26
Seventh latest SD subcategory data
1 byte 0 - 3
27
Data of hour meter for the seventh latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
28
Data on temperature for the seventh latest SD (TEMP1)
3 bytes 000 - 255
29
Eighth latest SD data
1 byte 0 - 5
30
Eighth latest SD subcategory data
1 byte 0 - 3
31
Data of hour meter for the eighth latest SD
7 bytes
1st-5th byte: Hour, 6th-7th byte: Minute
32
Data on temperature for the eighth latest SD (TEMP1)
3 bytes 000 - 255
Notes: • Ignore the 2-byte checksum at the end.
• For details, see "Description on shutdown".
• Description of shutdown • Module microcomputer IIC: Data on SD subcategory
Data
Factors of shutdown
0 No abnormality
1 IC4
2 Module microcomputer IIC
3 Abnormality in RST2 (power decrease of DC-DC converter)
4 Panel having high temperature
5 Audio failure (speakers short-circuited)
6 Reservation
7 Reservation
8 Reservation
9 Reservation
A Reservation
B Reservation
C Reservation
D Reservation
E Reservation
F Reservation
Data
Factors of shutdown
0 No subcategory
1 EEPROM (DIGITAL VIDEO Assy : IC5206)
2 EEPROM (PANEL IF Assy : IC4002)
3 Volume IC
4 Reservation
5 Reservation
6 Reservation
7 Reservation
8 Reservation
9 Reservation
A Reservation
B Reservation
C Reservation
D Reservation
E Reservation
F Reservation
