Pioneer PDP-6071PU User Manual

PDP-6071PU
114
1234
1234
C
D
F
A
B
E
Under Cover (60)
4
1
Remove the 16 screws.
2
Remove the 21 screws.
3
Remove the under cover (60).
Exchange of 607 SCAN A and B Assys
5
1
Loosen the jumper wire.
2
Remove the two screws.
3
Remove the function button shield with PCB.
3
TANSHI Assy
SP TERMINAL Assy
×16
1
2
2 2
2
2
2
2
2
2
2 2 2 2 2
2
2
22
2
2
2
Under cover (60)
Function button shield SIDE KEY Assy
22
1
3
