Pioneer PDP-6071PU User Manual

PDP-6071PU
67
5678
56
7
8
C
D
F
A
B
E
CN3001 (D11) ↔ MAIN ASSY CN4001 (M1)
Pin No. Pin Name I/O Function Voltage (V) TP
1 GND – GND
2 V+3.3V_UCOM2 I Power supply for module microcomputer 3.3
–
0
–
–
–
–
–
–
–
0
0 to 3.3
0 to 3.3
0 to 3.3
0
–
TP3002
TP3017
TP3021
TP3037
TP3036
TP3035
–
TP3034
–
–
TP3059
TP3058
TP3057
TP3056
TP3055
TP3054
TP3053
TP3052
TP3051
TP3050
–
TP3069
TP3068
TP3067
TP3066
TP3065
TP3064
TP3063
TP3062
TP3061
TP3060
–
TP3079
TP3078
TP3077
TP3076
TP3075
TP3074
TP3073
TP3072
TP3071
TP3070
–
TP3039
TP3020
TP3166
TP3163
TP3016
–
3 INP_MUTE O Output bufffer control signal of MAIN assy
4 THEATER I Control signal for pure cinema 0
5VDIVertical synchronized signal 0 to 3.3
6HDIHorizontal synchronized signal 0 to 3.3
0 to 3.3
8 GND – GND
7DEIData enable signal
9 CLK I Data clock signal
10 GND – GND
0 to 3.3
11 GND – GND
12 VIDEO_R9 I 10 bit video signal input (RED) 0 to 3.3
13 VIDEO_R8 I 10 bit video signal input (RED) 0 to 3.3
14 VIDEO_R7 I 10 bit video signal input (RED) 0 to 3.3
15 VIDEO_R6 I 10 bit video signal input (RED) 0 to 3.3
16 VIDEO_R5 I 10 bit video signal input (RED) 0 to 3.3
17 VIDEO_R4 I 10 bit video signal input (RED) 0 to 3.3
18 VIDEO_R3 I 10 bit video signal input (RED) 0 to 3.3
19 VIDEO_R2 I 10 bit video signal input (RED) 0 to 3.3
20 VIDEO_R1 I 10 bit video signal input (RED) 0 to 3.3
21 VIDEO_R0 I 10 bit video signal input (RED) 0 to 3.3
22 GND – GND
23 VIDEO_G9 I 10 bit video signal input (GREEN) 0 to 3.3
24 VIDEO_G8 I 10 bit video signal input (GREEN) 0 to 3.3
25 VIDEO_G7 I 10 bit video signal input (GREEN) 0 to 3.3
26 VIDEO_G6 I 10 bit video signal input (GREEN) 0 to 3.3
27 VIDEO_G5 I 10 bit video signal input (GREEN) 0 to 3.3
28 VIDEO_G4 I 10 bit video signal input (GREEN) 0 to 3.3
29 VIDEO_G3 I 10 bit video signal input (GREEN) 0 to 3.3
30 VIDEO_G2 I 10 bit video signal input (GREEN) 0 to 3.3
31 VIDEO_G1 I 10 bit video signal input (GREEN) 0 to 3.3
32 VIDEO_G0 I 10 bit video signal input (GREEN) 0 to 3.3
33 GND – GND
34 VIDEO_B9 I 10 bit video signal input (BLUE) 0 to 3.3
35 VIDEO_B8 I 10 bit video signal input (BLUE) 0 to 3.3
36 VIDEO_B7 I 10 bit video signal input (BLUE) 0 to 3.3
37 VIDEO_B6 I 10 bit video signal input (BLUE) 0 to 3.3
38 VIDEO_B5 I 10 bit video signal input (BLUE) 0 to 3.3
39 VIDEO_B4 I 10 bit video signal input (BLUE) 0 to 3.3
40 VIDEO_B3 I 10 bit video signal input (BLUE) 0 to 3.3
41 VIDEO_B2 I 10 bit video signal input (BLUE) 0 to 3.3
42 VIDEO_B1 I 10 bit video signal input (BLUE) 0 to 3.3
43 VIDEO_B0 I 10 bit video signal input (BLUE) 0 to 3.3
44 GND – GND
45 RESERVE (N.C.) – Reserve
46 AC_OFF (N.C.) O AC state input
47 TXD_MD O UART communication with MAIN u-com
48 RXD_MD I UART communication with MAIN u-com
49 REQ_MD O Communication demand to main system
50 MODE O Detection of MAIN Assy connection
60 DIGITAL ASSY
