PDP-6071PU
68
1234
1234
C
D
F
A
B
E
CN3151 (D24) ↔ SENSOR ASSY CN3651 (TE1)
–
TP3159
TP3168
TP3169
TP3161
–
Pin No. Pin Name I/O Function Voltage (V) TP
1
V+3.3V_EEP
O Power supply output for memory 3.3
2
E_SCL
O IIC communication clock signal 0 to 3.3
3
E_SDA
O IIC communication data signal 0 to 3.3
4
TEMP1
I Panel temperature sensor signal 0.8
5
GND
– GND
CN3601 (D21) ↔ POWER SUPPLY UNIT (P4)
Pin No. Pin Name I/O Function Voltage (V) TP
1
V+12V
I +12 V power supply input 12 TP3505
2
V+12V
I +12 V power supply input 12 TP3506
3
GND
– GND – TP3608
4
GND
– GND – –
5
V+3.3V_STB
I STB3.3 V power supply input 3.3 TP3638
6
GND
– GND – –
7
M_SW_DET
I Mechanism switch detection signal input 3.3 TP3639
8
EXT_PD
O Power down signal 0 TP3632
9
VSUS_ADJ
O VSUS power supply adjustment signal 1.7 TP3633
10
PS_PD
I Power supply PD signal 0 TP3634
11
RELAY
O Relay control 3.3 TP3626
12
DRF_B
O Large power supply ON/OFF control signal 3.3 TP3616
13
AC_DET
I AC power supply state input 3.3 TP3635
14
PD_TRG_B
I Power down trigger signal 3.3 TP3636
