Controls and displays
02
18
En
11
TUNER EDIT
Use with ////ENTER to memorize and name
stations for recall (page 51).
12
BAND
Switches between AM and FM radio bands (page 51).
13 Listening mode buttons
AUTO SURR/ALC/STREAM DIRECT –
Switches
between Auto Surround
(page 55)
, Auto Level Control,
Optimum Surround
1
mode and Stream Direct mode
(page 58)
.
HOME THX – Press to select a Home THX listening
mode (page 56).
STANDARD SURROUND – Press for Standard
decoding and to switch various modes (2 Pro Logic,
Neo:6, etc.) (page 55).
ADVANCED SURROUND – Use to switch between
the various surround modes (page 57).
STEREO – Switches between stereo playback and
Front Stage Surround Advance modes (page 57).
14
MULTI-ZONE
controls
If you’ve made MULTI-ZONE connections (see MULTI-
ZONE setup on page 36) use these contr ols to control the
sub zone from the main zone (see Using the MULTI-ZONE
controls on page 74).
15
SPEAKERS
Use to change the speaker terminal (page 74).
16
HOME MENU
Press to access the Home Menu (pages 42, 45, 68, 99,
109 and 112).
17
RETURN
Press to confirm and exit the current menu screen.
18 HDMI input connector
Use for connection to a compatible HDMI device (Video
camera, etc.) (page 38).
19
iPod/iPhone/USB
terminals
Use to connect your Apple iPod as an audio and video
source, or connect a USB device for audio and photo
playback (page 38).
20
MCACC SETUP MIC
jack
Use to connect the supplied microphone (page 43).
21
PHONES
jack
Use to connect headphones. When the headphones are
connected, there is no sound output from the speakers.
1Optimum Surround mode is only apply to the SC-LX83.
SC-LX83_73_DLPW.book 18 ページ ２０１０年５月１９日 水曜日 午後２時７分
