Piper Arrow IV Turbo User Manual

VENDOR PUBLICATIONS.
ENGINE (LYCOMING):
Overhaul Manual = AVCO LYCOMING - OVERHAUL MANUAL
DIRECT DRIVE ENGINE - P/N 60294-7
Avco Lycoming Division
Williamsport, Pa. 17701
Parts Catalog = AVCO LYCOMING - P/N PC-102
Avco Lycoming Division
Williamsport, Pa. 17701
Operators Handbook =AVCO LYCOMING O-360, HO-360, IO-360,
AIO-360, HIO-360, LIO-360 and TIO-360
SERIES AIRCRAFT ENGINES - P/N 60297-12
Avco Lycoming Division
Williamsport, Pa. 17701
ENGINE (CONTINENTAL):
Overhaul Manual = CONTINENTAL - OVERHAUL MANUAL
Form No. X-30030A
Teledyne Continental Motors
Aircraft Products Division
Mobile, Alabama 36601
Parts Catalog = CONTINENTAL - Form No. X-30031A
Teledyne Continental Motors
Aircraft Products Division
Mobile, Alabama 36601
Operators Handbook = CONTINENTAL - Form No. X-30512
Teledyne Continental Motors
Aircraft Products Division
Mobile, Alabama 36601
PROPELLER:
Overhaul Instructions = HARTZELL COMPACT CONSTANT SPEED
and FEATHERING PROPELLER - P/N 113A
Hartzell Propeller Inc.
Piqua, Ohio 45356
Service Manual = McCAULEY C200 SERIES CONSTANT
SPEED PROPELLERS - P/N 780630
McCauley Accessory Division
3535 McCauley Drive
Vandalia, Ohio 45377
MAGNETOS:
Installation, Operation
and Maintenance
Instructions = D-2000 and D-2200 SERIES MAGNETO
IGNITION SYSTEM - P/N L-928
Bendix Electrical Components Division
Sidney, New York 13838
AUTOPILOT: CENTURY 41 AUTOPILOT, Edo-Aire Mitchell
Box 610, Mineral Wells, Texas 76067
Introduction
Page - 2
Revised: August 17, 1982
1A3
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL

Piper Arrow IV Turbo Specifications

General

Manufacturer	Piper Aircraft
Model	Arrow IV Turbo
Horsepower	200 hp
Seating Capacity	4
Landing Gear	Retractable tricycle
Range	773 nautical miles
Service Ceiling	20, 000 ft
Fuel Capacity	72 gallons
Propeller	2-blade constant speed
Max Takeoff Weight	2, 900 lb (1, 315 kg)
Stall Speed (Flaps Down)	55 knots
Rate of Climb	1, 000 ft/min
