CHAPTER 6- DIMENSIONS AND AREAS
TABLE OF CONTENTS/EFFECTIVITY
CHAPTER
SECTION GRID
SUBJECT SUBJECT NO. EFFECTIVITY
6-10-00 DIMENSIONS 1B18 2-79
6-20-00 Station Reference Lines 1B24 2-79
6-30-00 Access and Inspection Provisions 1C2 2-79
6-40-00 Weight and Balance Data 1C2
6-50-00 Serial Number Plate 1C2
6- Cont./Effec.
Page - 1
Revised: February 23, 1979
