Piper Arrow IV Turbo User Manual

Revisions to Maintenance Manual 761 694 issued December 1, 1978 are as follows:
Revisions
Date Aerofiche Card Effectivity
ORG 781201 December 1, 1978 1, 2, and 3
PR790223 February 23, 1979 1, 2, and 3
PR791106 November 6, 1979 1, 2, and 3
PR800818 August 18, 1980 1, 2, and 3
PR810724 July 24, 1981 1, 2, and 3
PR811221 December 21, 1981 1, 2, and 3
PR820817 August 17, 1982 1, 2, and 3
PR830713 July 13, 1983 1, 2, and 3
PR840808 August 8, 1984 1, 2, and 3
IR860730 July 30, 1986 (Interim) 1
IR860921 September 21, 1986 (Interim) 1
IR950227 February 27, 1995 (Interim)* 1, 2, and 3
*INTERIM CHANGE TO MAINTENANCE MANUAL 761-694
Chapters 5, 6, and 27 of Card 1, Chapters 32 and 51 of Card 2, and Chapter 71 of
Card 3 have been revised. There are no other changes included in this interim change
revision. Please discard your current cards 1, 2, and 3, and replace them with the
revised ones.
SERIAL NUMBER INFORMATION
PA-28RT-201, Arrow IV - 1979 - Serial Numbers 28R-7918002 to 28R-7918267 inclusive
PA-28RT-201, Arrow IV - 1980 - Serial Numbers 28R-8018001 to 28R-8018106 inclusive
PA-28RT-201, Arrow IV - 1981 - Serial Numbers 28R-8118001 to 28R-8118082 inclusive
PA-28RT-201, Arrow IV - 1982 - Serial Numbers 28R-8218001 to 28R-8218026 inclusive
PA-28RT-201T, Turbo Arrow IV - 1979 - Serial Numbers 28R-7931002 to 28R-7931310 inclusive
PA-28RT-201T, Turbo Arrow IV - 1980 - Serial Numbers 28R-8031001 to 28R-8031178 inclusive
PA-28RT-201T, Turbo Arrow IV - 1981 - Serial Numbers 28R-8131001 to 28R-8131208 inclusive
PA-28RT-201T, Turbo Arrow IV - 1982 - Serial Numbers 28R-8231001 to 28R-8231080 inclusive
PA-28RT-201T, Turbo Arrow IV - 1983 - Serial Numbers 28R-8331001 to 28R-8331051 inclusive
PA-28RT-201T, Turbo Arrow IV - 1984 - Serial Numbers 28R-8431001 to 28R-8431032 inclusive
PA-28RT-201T, Turbo Arrow IV - 1985 - Serial Numbers 28R-8531001 to 28R-8531015 inclusive
PA-28RT-201T, Turbo Arrow IV - 1986 - Serial Numbers 28R-8631001 and 28R-8631005 inclusive
PA-28RT-201T, Turbo Arrow IV - 1987 - Serial Numbers 28R-8631002 to 28R-8631004 inclusive
Serial Numbers 2831001 to 2831033 inclusive
PA-28RT-201T, Turbo Arrow IV - 1988 - Serial Numbers 2831034 to 2831038 inclusive
Introduction
Page-5
Interim Revision: February 27, 1995
3A6
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL

Piper Arrow IV Turbo Specifications

General

Manufacturer	Piper Aircraft
Model	Arrow IV Turbo
Horsepower	200 hp
Seating Capacity	4
Landing Gear	Retractable tricycle
Range	773 nautical miles
Service Ceiling	20, 000 ft
Fuel Capacity	72 gallons
Propeller	2-blade constant speed
Max Takeoff Weight	2, 900 lb (1, 315 kg)
Stall Speed (Flaps Down)	55 knots
Rate of Climb	1, 000 ft/min
