ENGLISH
14
Element
Temp Set/Act
Time Smoke
F/C
When connected to a power source, the Power Button will glow blue. Press the Power Button to power on the unit. Once
the Power Button is pressed, the Digital LCD Screen will light up, displaying that it is ready to operate. Press and hold
the button to turn the unit off.
Element
Temp Set/Act
Time Smoke
F/C
The Temperature Switch Button is used to change the temperature readout on the Digital LCD Screen. Press the button
to switch to Celsius (ºC) or to Fahrenheit (ºF), as preferred. Default is set to Celsius.
Element
Temp Set/Act
Time Smoke
F/C
The Element Light Indicator is used to display if the heating element is on or off. If the light glows, the heating element
is working and is on. If the light is off, the element is off. The heating element will stay on if the temperature
is below the temperature. Once the temperature is reached, the heating element will automatically turn off.
PRIME
SMOKE
150º 400º
HIGH
175º 350º
200º 300º
225º 250º
PROBE 1
ACTUAL
F
COOK
PROBE 2
F
PELLET VERTICAL SMOKER
-COPPERHEAD (WALMART)
F / C
The Digital LCD Screen is used as the information center for your unit. The Digital LCD screen will display your Desired
Cook Temperature (), Actual Cook Temperature (), Meat Probe Temperature (if connected), and any error
messages. If only one Meat Probe is connected, only one reading will be displayed. Temperature can be displayed in
either Fahrenheit or Celsius.
Element
Temp Set/Act
Time Smoke
F/C
Element
Temp Set/Act
Time Smoke
F/C
The Adjustment Arrows allow you to increase or decrease the and on the Control Board. Press and hold the
buttons to increase or decrease the value faster.
Temp
Press the Button on the Control Board to adjust the cooking temperature.
• Press once to select the temperature setting, then the adjustment arrows to change the temperature in five-degree
increments. Press once again to lock-in the temperature setting once the changes are finished.
The heating element will not turn on until is also set. Default element temperature is set to 37ºC / 100 ºF.
Time
Press the Button on the Control Board to adjust the cooking time.
• Press once to select the time setting, then press the adjustment arrows to change the hours. Changes are in 1
hour increments (ranging from 00-99).
• Press once again to select the minutes setting, then press the adjustment arrows to change the minutes. Changes
are in 10 minute increments (ranging from 00-50).
• Press twice to lock in the time setting once the changes are finished.
Set/Act
Press the / Button on the Control Board to display the desired setpoint (SET) or the actual/current (ACT) time and
temperature. The display shows the actual (ACT) settings for TIME and TEMP by default.
• To view the TIME and TEMP setpoints, press the / button once. After 15 seconds, the display will switch
back to the actual (ACT) settings.
• To change a setpoint, press the / button once, followed by pressing TIME or TEMP. Next. press the
adjustment arrows to change the setting.
Smoke
Press the Button on the Control Board to manually turn on the heating element for a 20-minute cycle. "FS" will
appear on the screen, indicating "Fast Smoke". This is mostly used to recover lost smoke from opening the cabinet door,
or when starting a new smoke profile with freshly added wood chips.
• To stop the cycle before the 20 minutes, press the SMOKE Button twice.
PROBE 1
ACTUAL
F
COOK
F
PROBE 2
F
Element
Temp Set/Act
TimeSmoke
F/C
