Pit Boss PBVPS1 - Electrical Wire Diagram; PB Electric Requirements and Diagram

23
FUEL INPUT
RATING:
1.1 /
2.4 /
INDEX
  
  
  
  
  
  
P
P
R
Y
Y
YP
K
K
W
G
W
W
W
R R
WW
W
W
YY
K
W
IGNITER ASSEMBLY /
HD CARTRIDGE HEATER
200, 120, 1.6 
0.375”  5.000”
BURN POT
DRAFT FAN
120, 60,
0.45 , 1 
GROUNDED
POWER CORD
1, 105°/221°,
183  
AUGER MOTOR
& FEED SYSTEM
120, 60, 0.45 ,
2  
GROUND
TEMPERATURE
PROBE
TEMPERATURE PROBE
SPADE CONNECTORS
FAST-BLOW FUSE
5 
CONTROL BOARD
  
The Control Board system is an intricate and valuable piece of technology. For protection from power surges and electrical shorts,
consult the wire diagram below to ensure your power source is sufficient for the operation of the unit.
PB – ELECTRIC REQUIREMENTS
120V, 2.1AMP, 60HZ, 250W, 3-PRONG GROUNDED PLUG
: Electrical components, passed by product safety testing and
certification services, comply with a testing tolerance of ± 5-10 percent.
